Climbing module

We have created the reference J5904® in our "Ninja trails" range. This module is accessible from 6 years. It can accommodate up to 7 users.

The size of the module is: 5.34 m wide, 1.61 m. deep, 3.01 m. high. The free fall height (FFH) is 2.70 m.

8 play functions

traversing
Traversing x2
Successfully traversing promotes self-confidence and motivates the child to undertake more complex movements.
climbing
Climbing x5
Climbing develops the child's motor and psychomotor skills as they balance and deliberate to progress in their movement.
climbing
Climbing x1
Climbing promotes dexterity, balance and coordination of movements. On the way up, the child learns to deal with height and space.

Specifications

Age range: 6+
Number of users: 7 users
FFH : 2.70 m
Size: 5.34 x 1.61 x 3.01 m

Equipment installation

Number of installers: 2
Installation time: 04:00:00
Concrete volume: 0.85 m3
Surface: 44.00 m2
Total weight: 245.33 kg
Weight of the heaviest element: 25.81 kg

Certification

The products in our catalogues all comply with current European standards and are TÜV approved. Our website offers many additional configurations for which Proludic certifies compliance.
- JXXXX TÜV certification
- JXXXX* Proludic Certification
Side view
Side view
View from above
View from above

Materials

The 125mm diameter posts

The 125mm diameter posts are made of painted galvanised steel. The grained finish has a slightly undulating surface for increased scratch resistance. The caps are made of... rotary moulded polyethylene. Read more

The coloured panels

The coloured panels are made from a 13mm thick compact material (HPL). Robust in construction, it has excellent weather and vandal resistance properties.

The tubes

The tubes are made of 40mm diameter stainless steel, guaranteeing lasting durability and reliability of the equipment.

The platform floor

The platform floor is made from a 18mm thick, non-slip polyethylene material.

The climbing holds

The climbing holds are made of polyamide for its strength and rigidity.

The fixings

The fixings are made of stainless or plated steel and protected by anti-vandalism polyamide caps.
