J56012 - Playgrounds - Multiplay equipment

We have created the reference J56012® in our "Kanopé" range. This play equipment is accessible from 2 years. It can accommodate up to 99 users.

The size of the module is: 15.57 m length, 10.22 m width, 6.86 m. high. The free fall height (FFH) is 2.97 m.

83 play functions

Role play x6

Role play promotes the child's intellectual and social skills.

Sliding x3

Sliding is always exciting and fun. On a classic slide or a sliding pole, on your stomach, on your back, as you please.

Meeting x8

Playing together, children meet new faces, new behaviors, new personalities, and how to interact.

Resting x4

Resting allows the child to recover from their exertions, and also improve their concentration.

Handling x8

Handling is a great activity for developing motor skills and abilities in young children while having fun.

Crawling x1

Crawling is a fun exercise that allows young children to become aware of their body in a small space.

Swinging x3

To create movement, children must be able to coordinate their arms, legs and vision in a coordinated fashion.

Balancing x3

Balancing involves learning to manage empty space in activities at height, when hanging or on narrow surfaces.

Thinking x3

Thinking helps children become more independent and gain self-confidence through increased understanding and self-awareness.

Sound stimulation x2

Fun sound activities bring liveliness to play areas, and are often shared by several children!

Tactile stimulation x9

Each touch-stimulating activity enables children to refine their manual dexterity skills, and the coordination of their gestures.

Visual stimulation x13

It awakens curiosity and memorising, stimulating concentration to better assimilate details, or to succeed in the association of colors.

Climbing x9

Climbing promotes dexterity, balance and coordination of movements. On the way up, the child learns to deal with height and space.

Traversing x3

Successfully traversing promotes self-confidence and motivates the child to undertake more complex movements.

Hiding x4

Feel the excitement of being hidden somewhere, and then the pleasure of finally being found.

Sheltering x4

Finding a small refuge to shelter in ensures children have a space of their own.

Specifications

Age range:	2+
Number of users:	99 users
FFH :	2.97 m
Size:	15.57 x 10.22 x 6.86 m

Equipment installation

Number of installers:	3
Installation time:	35:00:00
Concrete volume:	2.50 m3
Surface:	119.50 m2
Total weight:	4383.58 kg
Weight of the heaviest element:	72.00 kg

Environmental Indicators

Repairability

9.48 /10

Downloads

Technical fact sheet

Materials sheet*

JPEG Image

2D DWG

3D DWG

Certification

The products in our catalogues all comply with current European standards and are TÜV approved. Our website offers many additional configurations for which Proludic certifies compliance.

Materials

The 95 x 95mm posts are made of painted galvanised steel, ensuring robustness and durability.

The 125mm diameter posts are made of painted galvanised steel. The two-tone grey grained finish has a slightly undulating surface for increased scratch resistance. The caps... are made of injection moulded polyamide. Read more

The coloured panels are made from a 13mm thick compact material (HPL). Robust in construction, it has excellent weather and vandal resistance properties.

The slatted fences are made of composite wood (slats of 70 x 30 mm), which is a chip and split resistant waterproof material with UV protection.

The decorative fence panels are made of 3mm thick painted aluminium sheets.

The wall panels are made of 3mm perforated aluminium sheet coated with a polyester epoxy lacquer.

The panels are made of stainless steel mesh netting, Ø 6mm.

The platforms are made from a 12.5mm thick textured and non-slip compact material (HPL).

The soft ramp is made of a woven strip with rubber surface.

The tubes are made of 40mm diameter stainless steel, guaranteeing lasting durability and reliability of the equipment.

The 16mm diameter ropes are made of galvanised steel cable covered with polyester. The cables are linked together and held in place by injected polyamide spheres.
